Aventon Level 3 Sandstone
Tax included
Shipping calculated at checkout
Only 1 in stock
Description
From the USA's #1 e-bike brand, take your commutes to the next LEVEL. The all-new Level 3 comes fully equipped with everything you need to trade your daily drives for daily rides. A rear rack and fenders ensures you can carry necessities while staying clean and dry during your rides. A front suspension fork and suspension seat post provide maximum comfort on rougher terrain. Our ACU technology provides peace of mind with GPS† tracking, auto-lock, unusual movement detection, alarm system, and much more to keep your bike safe and secure. Comfortable geometry paired with an adjustable stem ensure the perfect fit, while the implementation of Ride Tune capabilities allow user adjustments. Built-in indicators provide better safety when riding around town. Ditch the traffic, and elevate your daily commutes with the Level 3. connection. A complimentary 4G connection subscription is included for the first year, beginning from the product service registration date.
Specifications
⚡ Power & Electronics
| Feature | Specification |
| Top Speed | 32 km/h (Throttle) / 45 km/h (Pedal Assist) |
| Motor | 300W Torque-Sensing Hub Drive |
| Battery | Removable Internal 36V, 20Ah (733Wh) with LG 21700 cells |
| Battery Weight | 3.9 kg |
| Charger | 36V Output (42V / 4A), ~5 hours charge time |
| Display | Aventon BC280 |
| Throttle | Aventon LH Handlebar Mounted |
| Sensors | Double-Sided Bottom Bracket Torque Sensor |
| E-Bike Class | Class 2 |
| Lights | Front & Rear Integrated Lights |
🚴 Frame & Suspension
| Feature | Specification |
| Frame | 6061 Aluminum, Gravity Cast Front Triangle |
| Fork | Aventon Suspension Fork, 80mm travel w/ lockout, coil spring (15x100mm thru-axle, 43mm offset) |
| Fork Spacing | 110mm |
| Rear Spacing | 142mm |
| Water Resistance | IPX6 |
⚙️ Drivetrain & Components
| Feature | Specification |
| Shifter | Shimano 8-Speed Trigger SL-M315-8R |
| Rear Derailleur | Shimano Altus RD-M310 |
| Cassette | Shimano CS HG200-8 (12-32T, 8-Speed) |
| Chainring | 48T |
| Crankset | 3-Piece, 170mm crank arm |
| Bottom Bracket | Square Taper, Sealed, double-sided Torque Sensor (83mm x 158.5mm) |
| Chain | 7/8-Speed 120L |
| Pedals | 9/16" Composite Platform |
🛑 Brakes & Wheels
| Feature | Specification |
| Brakes | Tektro HD-E3520 Hydraulic disc brakes, front and rear |
| Tyres | Kenda Kwick Seven-5 Sport K1052-006 (27.5" x 2.20") |
| Front Wheel | 27.5", 13g, 36-hole, Double-Wall Aluminum, Thru-Axle, Schrader Valve |
| Rear Wheel | 27.5", 12g, 36-hole, Double-Wall Aluminum, Nutted Hub Drive, Schrader Valve |
🛋️ Cockpit & Accessories
| Feature | Specification |
| Handlebars | Aluminum 31.8mm, 680mm width |
| Grips | Aventon Lock-on Grips |
| Headset | Sealed Bearing Headset |
| Saddle | Aventon Saddle |
| Seatpost | 30.9mm Aventon Suspension Seatpost (50mm travel) |
| Fenders | Included |
| Rear Rack | Included (27 kg weight limit) |
